Hi friends if u hav problem with 5200 restarting....then 1st flash ur phone with latest version & if ur problem not solves with flash then change this ic prob will be solve tested Solution
Hi friends in these days we hav some problems about chinese mobiles pinouts..there are some models pinouts available & some models not...most of models pinouts in infinity & find pinder...& some of models not here i sharing with u easiest way to find pinouts in chinese.. There are two things important to find pinout,,,,1st digital meter...commonoly every one hav it & second DC power suply....so lets if u hav both then simple :69::69::69: 1.Set power suply on 3.7 volts 2.Attach power suply's red & black wires to battery connecter posive & nagative like we check dead sets 3.Power on the mobile 4.Set digital meter on voltage 5.Put meter's black wire on gnd 6.Check with red wire on charging jeck 7.Then 2.73 volts is Rx & 2.80 Volts is Tx
I tested it on 4-5 mobiles--- one of them is here format & solved restart problem
COM14 [VCP0] selected Device: Autodetect 6205-6227 NOR Checking data, wait... advanced flash detection enabled eeprom backup enabled, it may takes several minutes ! Action: reset Boot... Press and HOLD Power button now ! baud autodetection active 19200 Connecting, wait... Initializing[6226:8A02:8A01]... chip: 0031:D693:C2D5 high speed disabled boot step size: 0002 Release Power button now ! Boot Done Initialize... detecting chip #00 in region #00... flash: 01227E22202200:29EA0000000000 flash: Amd AMD/Fujitsu std [D 0004x010000 003Ex040000 0004x010000] 16Mb detecting chip #01 in region #00... flash: 01227E22202200:29EA0000000000 flash: Amd AMD/Fujitsu std [D 0004x010000 003Ex040000 0004x010000] 16Mb number of flash chip/regions detected: 02/01 Initialize Done Set baud... 115200 Set baud Done Identification... device parameters autodetection in progress.. detecting chip #00 in region #00... flash: 01227E22202200:29EA0000000000 flash: Amd AMD/Fujitsu std [D 0004x010000 003Ex040000 0004x010000] 16Mb detecting chip #01 in region #00... flash: 01227E22202200:29EA0000000000 flash: Amd AMD/Fujitsu std [D 0004x010000 003Ex040000 0004x010000] 16Mb it's time to stop: 290000EA18F09FE518F09FE518F09FE518F09FE518F09FE5 number of flash chip/regions detected: 01/01 total flash region size: 01000000 detect device identification#1... detection phase #1... detect device identification#1 finished identification#1 structure: 2nd [enhanced] generation security area#1 is Ok security area#1 backup saved: C:\Program Files\InfinityBox\ChineseMiracle\backup_security\id.93DCB6B6.[M200DY_PCBV1_1_GPRS_MT6226_S01.DY1_EFARV_7N_2S_2C60_V03.BIN_ADFE5789].rpl New firmware detected: M200DY_PCBV1_1_GPRS_MT6226_S01.DY1_EFARV_7N_2S_2C60_V03.BIN - make "Repair security area" operation - send "backup_system_log_..." file to support - make "Read full flash" operation - send flash backup file(s) to support - include in your e-mail full text from phone back label (phone name etc.) identification#1 detection finished device-id: 93DCB6B6 identification#1 protocol ver: 04 ver. sw1: M200DY_PCBV1_1_GPRS_MT6226_S01.DY1_EFARV_7N_2S_2C60_V03.BIN ver. sw2: DY1_EFARV_7N_2S_2C60_V03 ffs offset/size: 00E00000/00200000 detect device identification#2... detection phase #1... . warning: optional information not found detect device identification#2 finished detecting eeprom/ffs area in 1 chip(s)... standard eeprom/ffs offset detected: 00E00000 flash: 01227E22202200:29EA0000000000 checking area[00000000]: 00000000-00FFFFFF... eeprom/ffs found near: 00E00000 detecting eeprom/ffs size... eeprom/ffs size: 00200000 ffs chip: 00 eeprom/ffs area: 00000000:00E00000-00FFFFFF reading [eeprom[M200DY_PCBV1_1_GPRS_MT6226_S01.DY1_EFARV_7N_2S_2C60_V03.BIN]]... file saved: C:\Program Files\InfinityBox\ChineseMiracle\backup_eeprom[M200DY_PCBV1_1_GPRS_MT6226_S01.DY1_EFARV_7N_2S_2C60_V03.BIN]_20080330-114532.B0E.bin flash: 01227E22202200:29EA0000000000 Identification Done Manipulation... Manipulation Done Finalization... Finalization Done Write... formatting... flash: 01227E22202200:29EA0000000000 Write Done file saved: C:\Program Files\InfinityBox\ChineseMiracle\backup_system_log_93DCB6B6_M200DY_PCBV1_1_GPRS_MT6226_S01.DY1_EFARV_7N_2S_2C60_V03.BIN_ADFE5789_20080330-114551.B0X.bin Finished, time used: 325 sec Remove/Install battery now !
