BEFORE TO DO SOMETHING BE SURE THAT THE CABLE IS 100% WORKING**. ALWAYS MAKE IMEI AND PM BACKUPS**.
Before make something stupid step read F.A.Q first. If you don't know something ask first.
FOLLOWING F.A.Q THREADS:
* How didn't break the phone by bad operations
* How erase phone flash
* When YOU need to do ASK2RPL calculations
* Invalid response from RAP3 boot
As we know, the new BB5 phones based on CPU RAPIDO_YAWE are supported by the MT-BOX - unlock. Increasingly, we get phones damaged by other tools ( J.X.X or UX - who should know then know). Old erase files are based on the RAPIDO CPU and will not work with the new BB5 series.
HOW TO USE
Anyone who uses the previous erase files then will know how working new erase function - based in the same way. Flash memory is erased depending of the flash size - from 0 to 128 MB or from 0 to 256 MB). The file should be set as MCU (you can see it in the picture under text). If You don't know something please visit my page - '
How erase phone flash'. Erasing proccess is the same, after flash erasing you should backup IMEI data and SIMLOCK values to factory state (before erasing), then flash with latest firmware version (highly recomended to restore the same version which was before erased)
SUPPORTED DEVICES:
At this moment we know about RAP and RAPIDO erase files. If you already tryed to erase RAPIDO_YAWE CPU based with RAPIDO erase file you see message:
Quote:
Boot...
MCU SW incompatible with ASIC
FAILED TO BOOT PHONE!!!
This means that the file ERASE is not compatible with your phone and is probably RAPIDO_YAWE CPU.
TESTED DEVICES:
All tested devices with RAPIDO_YAWE_V1.13_PA with 256 MB flash size by me and others members of GT forum:
* 5800 XpressMusic (RM-356 / RM-428) RAPIDOYAWE_V1.13_PA ---> 256 MB
* 6210 navigator (RM-367/386) RAPIDOYAWE_V1.13_PA ---> 256 MB
* 6210 navigator (RM-408/419) RAPIDOYAWE_V1.13_PA ---> 256 MB
* E66 (RM-343) RAPIDOYAWE_V1.13_PA ---> 256 MB
All supported device with RAPIDO_YAWE CPU not tested ! (for your own risk !!!):
* 5320 XpressMusic (RM-409) RAPIDOYAWE_V1.13_PA
* 6110 Navigator (RM-122) RAPIDOYAWE_V1.12_PA_385ZWK
* 6120 classic (RM-243) RAPIDOYAWE_V1.12_PA_385ZWK
* 6121 classic (RM-308) RAPIDOYAWE_V1.12_PA_385ZWK
* 6124 classic (RM-422) RAPIDOYAWE_V1.12_PA_385ZWK
* 6650 fold (RM-400) RAPIDOYAWE_V1.13_PA
* and other will be added as soon is possible
List of supported devices will be updating but before I need FULL LOG from flashing via FBUS. If You're not sure about your phone send message directly to me or to my mail
[email protected]Erase files will erase ALL data in phone flash - firmware and EEProm (SIMLOCK, ENERGY and RF CALIBRATION !) IF YOU DON'T HAVE VALID BACKUP FILES PHONE WILL BE DAMAGED - THEN YOU NEED ASK2RPL. IF YOU DON'T KNOW WHAT ABOUT SIZE CHIP - DON'T TOUCH! UNKNOWED OPERATION WILL KILL YOUR PHONE !
COPYRIGHTS
The file has the same rights as any work and effort and time.
Erase file is my property and Griffin Team - ALL RIGHTS RESERVED. ANY MODYFICATION WILL VISIBLE FOR ME AND GRIFFIN TEAM - CODE IS DECRYPTED.
FILE IS FOR GT FORUM MEMBERS ONLY AND FOR USERS WHO KNOW WHAT'S MEAN RESERVED RIGHTS.
SIGNING OF THE AUTHOR AS DIFFERENT THAN ME OR GRIFFIN TEAM IS PROHIBITED !
Internet is much OF LAMERS WHO sign your name under someone else's Work or Cheat. Not tolerate COPY / PASTE GUYS (e.x here from my ORYGINAL THREAD CONTENT HERE AFTER CONTENT MODiFICATION)
256MB_RAPIDO_YAWE_eraseThanks to irfanamin2
regards
Geo_izak
Show Posts
GReaaaaaaat...
